Cotton Cake Filter Press
  • Filter Area

  • Plate Quality

  • Flow

Leave Message For Price Inquiry Online

Product Description

Cotton cake filter press uses regenerable fibrous material as filter medium to filter oil traces, mechanical impurities and suspension complexes etc., the filtered liquid is clear and transparent. The material of filter plate is made of aluminum alloy and polypropylene, and the number of plates can be increased and decreased to suit different filter material.

It's mainly used in the following fields: fermentation broth, enzymes, RNA, Gelatin, food, beverage and other fields that in need of higher filter precision.

Click to expand to view the data
Technical Parameters
Filter area(m2) Plate size(mm) Plate tdickness(mm) Filtration pressure(Kg/cm2 Plate NO.(pcs) Max Feedinig Pressure(Kg/cm2 Total Volume(L) Dimensions L×W×H(mm) Flow(L/Min) Motor Power(KW) Rotating Speed(r/min) Squeezing Pressure(Mpa) Max Travel Limit of Closing Plate(mm)
8 φ500 50 ≤2 22 3 216 2630×1150×770 87 1.1 1460 12 350
5 φ400 50 ≤2 22 3 138 2630×1050×670 55 1.1 1460 12 350

Full Service System

As leading filter press manufacturer and supplier with 16 years histoy, we have build full set of service system, mainly including pre-sales service, sales service and after-sales service.

  • Pre-sales Service

    After understanding the customer’s requirements for equipment, cost budget and other aspects in detail, we will recommend professional and customized solution for customers.

  • Sales Service

    Communicate with customers timely, and continuously improve the product solution in accordance with customer requirements.

  • After-sales Service

    We have mature after-sales service management system, inlcuding product installation, tech training service, spare parts, on-site maintenance, etc.
