Stainless Steel Filter Press(For Fine Filtration)
  • Filter Area

  • Plate Quality

  • Flow

Leave Message For Price Inquiry Online

Product Description

The frame of the stainless steel filter press is made from 304 stainless steel, and the filter plate is made from 304 stainless steel (316L or PP is optional). It can be adapted to various filter board, filter paper, filter membrane, filter cloth, etc. as the filter medium. It has the characteristics of high sanitation level, high temperature resistance, high filtration precision, simple operation and good sealing performance.

Widely used in: liquid medicine, plasma, alcohol (beer, wine, liquor, etc.) beverages, fruit juice, various oils (edible oil, industrial oil, etc.), fine chemicals, electroplating water and other industries.

Click to expand to view the data
Technical Parameters
Model Filter area(m²) Plate Qty Flow(T/h) Plate Size(mm) Dimension(mm)
BASJL600-14 14 41 10-13 600x600 1750x870x1350
BASJL600-21 21 61 15-20 600x600 2100x870x1350
BASJL600-24 24 71 20-25 600x600 2250x870x1350
BASJL600-35 35 101 25-30 600x600 2800x870x1350

Full Service System

As leading filter press manufacturer and supplier with 16 years histoy, we have build full set of service system, mainly including pre-sales service, sales service and after-sales service.

  • Pre-sales Service

    After understanding the customer’s requirements for equipment, cost budget and other aspects in detail, we will recommend professional and customized solution for customers.

  • Sales Service

    Communicate with customers timely, and continuously improve the product solution in accordance with customer requirements.

  • After-sales Service

    We have mature after-sales service management system, inlcuding product installation, tech training service, spare parts, on-site maintenance, etc.
